Pentair Emergency Shut Off Switch for Pool and Spa | ES03

Pentair Emergency Shut-Off Switch | ES03

Pentair Emergency Shut-Off Switch For Residential and Commercial Pool and Spa Control Systems

The SVRS Alarm system can be used with the Emergency Shut-Off (ESO3)
accessory (connection cable sold separately) for new or existing pool and spa
commercial applications. In the event of an emergency, the pool or spa pump can
be shut off by pushing the ESO3 red emergency button. Depending upon how the
system is wired, this action interrupts power to the pump or other equipment
connected to the ESO3 circuit board. Pulling the emergency button back out will
return the pumps to normal operation, and shut off the ESO3’s alarm.

LX820 systems standard relays included are 20 amp 2HP.

Designed for retrofitting commercial spas where an emergency shut-off switch is required.

Can use with IntelliFlo® VS+ SVRS and IntelliPro® VS+ SVRS pumps.

Select a convenient location to mount the Emergency Shut-Off switch. Provide a double-gang electrical box.
The electrical box must be rated for outdoor use if the Emergency Shut-Off is located outside. Provide and
install a standard spring-wound timer for the jet pump and filter pump. Install cable, using plastic or metallic
conduit where cables run underground.
