Hayward SwimClear 325 Sq Ft Cartridge Pool Filter | W3C3030

Hayward SwimClear 325 Sq. Ft. Cartridge Pool Filter | W3C3030

The Hayward SwimClear 325 Sq. Ft. Multi-Element Cartridge Filter | W3C3030 is built for superior water clarity, energy efficiency, and long-lasting performance. Featuring a 325-square-foot filtration area, this system delivers powerful dirt-holding capacity while minimizing maintenance needs—often running through an entire season before cleaning is required. Designed with Hayward’s Quad-Cluster™ cartridge configuration, it captures fine debris efficiently without requiring backwashing or additional media, making it an eco-friendly and cost-effective choice for in-ground pools.

Its heavy-duty, glass-reinforced co-polymer tank withstands harsh environmental conditions, ensuring dependable operation year after year. The one-piece clamp design allows quick access to internal components for simplified servicing, while the high-capacity manual air relief valve ensures smooth and consistent water flow. With low head loss and optimized hydraulic performance, the SwimClear W3C3030 reduces energy consumption and keeps your pool sparkling clean with minimal effort.

Key Features of the Hayward SwimClear 325 Sq. Ft. Cartridge Pool Filter

• Powerful 325 Sq. Ft. Filtration Capacity: Provides superior water clarity and longer cleaning intervals through advanced Quad-Cluster™ cartridge design.

• Durable Glass-Reinforced Tank: Constructed from corrosion-resistant co-polymer materials engineered for years of reliable use in demanding pool environments.

• Energy-Efficient Flow System: Low head loss design minimizes pump strain and operating costs while maintaining optimal water circulation.

• Quick-Access Clamp Design: Heavy-duty tamper-proof clamp enables tool-free access to cartridge elements without disrupting plumbing connections.

• Fast Air Relief System: Manual air relief valve releases trapped air quickly with a simple quarter-turn, improving hydraulic efficiency and startup times.

• Advanced Manifold Design: Non-corrosive top plate ensures stable filtration and prevents unfiltered water bypass during operation.

• Versatile Plumbing Options: Includes 2” full-flow internal piping with unions accepting both 2” and 2.5” fittings for flexible installation.

• Easy Drainage System: Large 1.5” drain port allows rapid tank flushing and maintenance preparation.

• Extended Filter Cycles: High-capacity dirt-holding design allows for longer intervals between cleanings, reducing maintenance time and costs.

• Proven Hayward Engineering: Trusted performance and reliability make it a leading choice among pool professionals and homeowners alike.

Specifications

• Maximum Filtration Size: Filters out particulates as small as 30 microns
• Filtration Area: 325 square feet
• Cartridge: 4 Required (Included)
• Installation: 2 inch plumbing connections
• Flow Rate: Maximum flow rate of 122 gallons per minute (GPM)

Includes

• (1) Hayward W3C3030 SwimClear Cartridge Filter
• (4) Cartridge- CX580XRE
• (1) Manual Air Relief Valve- CCX1000V
• (1) Pressure Gauge- ECX2712B1
• (1) Clamp- DEX2421JKIT

*See manual page 10 for complete list
